| Standard Configuration | CPU | 32Bit Quad-Core ARM Cortex-A17，up to 1.8GHz |
| RAM and ROM | EMMC5.0 8GB DDR4 2GB Card Slot Micro SD*1(Biggest Support 32G) | |
| Display and TP | 17.3 inch ips-LCD,LED backlight, 1920*1080, Multi-touch,IPS Full Perspective，glass+glass | |
| Speaker | Built-in speaker 5W Audio Playback | |
| Wifi | IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i Enterprise level security which can apply WPA/WPA2 certification for WiFi. | |
| Bluetooth | BT2.1+EDR/3.0/4.1 LE | |
| Ethernet | 10M/100M | |
| Interfaces | Power Port*1 RJ11Port（4-wire 232 serial Port）*1 RJ12 Port（Cashbox）*1 Typec USB*1 USB Host*4 | |
| Optional | Printer | Width: 80 +0/-0.5mm Speed: 150mm/s Automatic cutter Support 46 languages, ASCII Characters and Graphics |
| Code Scan | Embedded 2D code module, supporting 1D / 2D | |
| Note recycler | Note Dimensions Width: 60 - 82mm Length: 115 - 150mm/ Cashbox：300 standard | |
| 4G | LTE (FDD) B1/B2/B3/B5/B7/B8/B20 DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8 EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz DC-HSPA+ :Downlink:42 Mbps, Uplink: 5.76 Mbps LTE FDD: Downlink:100 Mbps, Uplink: 50 Mbps @Bandwidth 20M (CAT3) | |
| NFC | ISO/IEC 14443A,ISO/IEC 14443B,ISO/IEC 15693,MIFARE 1k/4K ,MIFARE DESFire,Sony FeliCa | |
| Other Parameters | Machine Size | 500mm*455mm*1520mm |
| N.W. | 40kg | |
| Color | Black | |
| OS | Android 7.1/11 | |
| Multi Application | Support multi application architecture,can simultaneously store and run multiple applications. | |
| Work Environment | Operating temperature:0℃ ～ 40℃ Storage temperature : -20℃ ～ 70℃ Relative humidity: 30℅～90℅ | |
| Power Adapter | Input:100V～240VAC，50～60HZ Output:12VDC，5A |
